Pixel pitch: 3mm / 6mm Pixel configuration: 1RGB LED type: SMD 2121 / SMD2525 LED type: Sanan LED cabin dimensions: 57 x 57 cm Brightness: 6000 nits Viewing angle: Horizontal: 140º, Vertical: 120º Driver IC: 16380 Refresh rate: 1920 Hz Scanning: 1/8 Power supply Power consumption (max.): 300 W/sq. Power consumption (average): 150 W/m2 Input voltage: AC 220V +/- 10% Mechanical data
LED cabin weight: 10 kg Material: Die-cast aluminum Waterproof: IP40
The kit does not include a plug Working and storage environment Storage: Temperature: -40℃ ~ 60℃, Humidity: 10% ~ 85% RH Working Environment: Temperature: -20℃ ~ 50℃, Humidity: 10% ~ 90% RH Lifespan (Typical): ≥100,000 hours MTBF: ≥10,000 hours
