LED SCREEN P4 51x51cm for outdoor use

screen and stacked on top of each other to make a large screen size.

Led

Pixel pitch: 4 mm

Pixel configuration: 1RGB

LED type: SMD 1921

LED type: Sanan

Cabinet

Pixels per square meter: 40,000 pixels

Number of LEDs per square meter: 40,000 pcs.

LED module resolution: 64 x 32

LED module size: 320 x 160 mm

LED cabin resolution: 128(W) x 128(H)

LED cabin dimensions: 51.2 x 51.2 cm

LED cabin area: 0.41 sq m.

Brightness: 2400 nits

Viewing angle: Horizontal: 140º, Vertical: 120º

IC Driver: 16208S

Refresh rate: 1920 Hz

Scanning: 1/8

Power supply

Power consumption (maximum): 300 watts / sq. m.

Power consumption (average): 100 watts/sq m.

Input voltage: AC 220V +/- 10%

Mechanical data

Weight of the LED cabin: 8 kg

Material: Die-cast aluminum

Waterproof: IP40

Service: Service from the rear

Working and storage environment

Storage: Temperature: -40℃ ~ 60℃, Humidity: 10% ~ 85% RH

Working Environment: Temperature: -20℃ ~ 50℃, Humidity: 10% ~ 90% RH

Lifespan (Typical): ≥100,000 hours

MTBF: ≥10,000 hours

Control: HUIDU HD-R708

It is recommended to use a HUIDU video player or processor (sold separately).
